| Models IGA-001, IGA-002 and IGA-003 |
IGASORP |
| Weight |
Weight |
- Balance Capacity* : 5 grams
- Weighing Range : Typically 200mg
- Resolution : 0.2§¶
- Long Term Stability : +/-1§¶
- Sample Containers
: Glass/Quartz/Ceramic/Steel Mesh
* Larger balance capacities and ranges available
|
- Balance Capacity* :5grams
- Weighing Range* :100mg/200mg/500mg
- Resolution : 0.1§¶ for 100mg range
- Long Term Stability : Nominal +/-1§¶
- Long Term Stability : /week
- Sample Containers : Glass/Steel Mesh
* Larger balance capacities and ranges
* available
|
| Pressure
|
Humidity
|
- Vessel : Pressurised-UHV SS316/SS304
- Vessel : Assembly
- Design Pressure : 20bars
- Design Temperature
: 500¡É at pressure 1000¡É
with Quartz Reactor (Ambient Pressure)
Pressure Sensors : Up to three per system ranging from 1 mbar to 20 bar
- Control : Accuracy : +/-0.025% of
:transducer span
(i.e 0.25 mbars for 1bar transducer)
|
- Sensor Accuracy :+/- 1%(0-90%RH)
- Sensor Accuracy :+/- 2%(90-100%RH)
- Sensor Response :15 seconds to 90% of
Sens-or Respons: e reading
- Control Range : 0%RH (Derermined by
- Control Range : gas supply) to 95%RH
- Regulation Accuracy :+/-0.1%RH
- Gas : Typicallydry air or nitrogen
- Max.flow rate : 500ml/min
|
| Temperature
|
Temperature
|
- Sensors : Type K or Platinum Resistance
- Range : Thermometers
- Cintrol Accuracy : +/- 0.05% to +/-¡É
- depending oncontrol equipment
- ACS : 50¡É Anti-condensation
- Protection (IGA-002)
|
- Bath Thermostat :
- Measurement Range : 5¡É to 85¡É
- Accuracy/Stability : +/-0.05¡É to +/-0.1¡É
- Accuracy/Stability : across range
- Internal Heater for Rapid Drying :
- Max. Temperature : 350¡É
- Max. Heating Rate : 10¡É/min
More detailed specifications for the complete IGA range can be obtained from relevant Technical Data Sheet (see below)
|
| Flow Control (IGA-003) |
Flow rate :
No. of Streams : Up to four
Optional balance purge for corrosive gases) |
